Planar Product Group

PLANAR - Spulenkörper für Löt-Technik

Planar Coil Formers For Soldering Technology

Planar coil formers for soldering technology in compact, low-profile transformer assemblies from E14-5 to E64-50.

Request QuoteRequest Sample

Technical Group Data

Group Characteristics.

Technical characteristics, article variants and verified product resources are consolidated at group level for fast engineering and procurement access.

Legacy Source

014/A01

Article Count

8

Series

PLANAR

Design

Coil former for soldering technology

Materials

PA66 A RV250 natural

Core Range

E14-5 - E64-50

Technical product overview · 8 verified article entries

Article Level

Available NORWE Types.

Select the required NORWE type by order code. Verified technical resources are linked to the article context so drawings, samples and quotations can be handled without losing product identity.
