M-EI-UI Product Group

M 42 - M 102b Coil Former Elements

M Coil Former Elements

Modular M coil former elements for laminated core transformer applications with separated winding areas and flexible connection concepts.

Request QuoteRequest Sample

Technical Group Data

Group Characteristics.

Technical characteristics, article variants and verified product resources are consolidated at group level for fast engineering and procurement access.

Core Range

M 42 - M 102b

Design

Modular coil former elements

Materials

PA66 p6g

RTI

+125°C

Pin / Blade System

Tin bronze, tin-plated solder pins or brass, tin-plated solder blades

Soldering Resistance

+350°C up to 2 seconds

Application

M laminated core transformer systems

Benefit

Primary and secondary areas can be wound in separate process steps while different connection technologies remain possible

Technical product overview · 24 verified article entries

Article Level

Available NORWE Types.

Select the required NORWE type by order code. Verified technical resources are linked to the article context so drawings, samples and quotations can be handled without losing product identity.
