EP 7 - EP 20 Coil Formers With Solder Pins

EP Coil Formers With Solder Pins

EP coil formers with straight press-fit solder pins for compact transformer applications with high inductance and low stray fields.

Request QuoteRequest Sample

Technical Group Data

Group Characteristics.

Technical characteristics, article variants and verified product resources are consolidated at group level for fast engineering and procurement access.

Core Range

EP 7 - EP 20

Connection

Straight press-fit solder pins

Materials

PET rtg natural

RTI

+155°C

Pin System

Tin bronze, tin-plated solder pins

Soldering Resistance

+350°C up to 2 seconds

Application

Compact EP transformers, high-inductance designs and low-stray-field magnetic assemblies

Benefit

Supports radial wire termination, reliable wire guidance, strain relief and defined PCB spacing

Technical product overview · 14 verified article entries

Article Level

Available NORWE Types.

Select the required NORWE type by order code. Verified technical resources are linked to the article context so drawings, samples and quotations can be handled without losing product identity.
